MAX31865ATP+
Converts two-, three-, or four-wire platinum RTD resistance into a 15-bit digital temperature measurement over SPI.
- Manufacturer
- Analog Devices
- Product type
- RTD-to-digital converter
- Package
- TQFN-20, exposed pad (5 x 5 mm)
In stock
- Available quantity
- 27,355 PCS
- Shipment from
- HONG KONG
Third-party escrow supported
60-day warranty from delivery
Request a quote
Send your requirements for a quote.
MAX31865ATP+
Converts two-, three-, or four-wire platinum RTD resistance into a 15-bit digital temperature measurement over SPI.
| Manufacturer |
Analog Devices |
|---|---|
| Product type |
RTD-to-digital converter |
| Package |
TQFN-20, exposed pad (5 x 5 mm) |
| RTD support |
PT100 to PT1000; 2-, 3- or 4-wire |
| ADC resolution |
15-bit |
| Interface |
SPI |
🚚 Free shipping on U.S. orders of $100 or more
For orders under $100, shipping costs $8–$20
Details
Ships from U.S. warehouse (City of Industry, CA)
Product Attributes
Product Attributes
| Packaging / pack quantity | Tube / 60 pcs |
|---|---|
| Product status | In production |
| Temperature accuracy | 0.5°C maximum over all operating conditions |
| Conversion time | 21 ms maximum (continuous conversion, 50 Hz notch) |
| Nominal temperature resolution | 0.03125°C; varies with RTD nonlinearity |
| Input overvoltage protection | ±45 V |
