ULN2803ADWR
Eight-channel Darlington transistor array for switching loads from logic control signals.
- Manufacturer
- Texas Instruments
- Product type
- Darlington Transistor Array
- Package
- 18-lead SOIC (DW)
In stock
- Available quantity
- 29,215 PCS
- Shipment from
- HONG KONG
Third-party escrow supported
60-day warranty from delivery
Request a quote
Send your requirements for a quote.
ULN2803ADWR
Eight-channel Darlington transistor array for switching loads from logic control signals.
| Manufacturer |
Texas Instruments |
|---|---|
| Product type |
Darlington Transistor Array |
| Package |
18-lead SOIC (DW) |
| Channels |
8 |
| Operating temperature |
−40 °C to +85 °C |
| Manufacturer lifecycle |
Obsolete |
| Package / mounting |
18-lead SOIC (DW) · Surface mount |
🚚 Free shipping on U.S. orders of $100 or more
For orders under $100, shipping costs $8–$20
Details
Ships from U.S. warehouse (City of Industry, CA)
Product Attributes
Product Attributes
| Packaging / pack quantity | Tape & reel / standard quantity on request |
|---|---|
| Product status | Obsolete |
| Collector-emitter voltage | 50 V (maximum) |
| Collector current | 500 mA per output (rated) |
| Input resistor | 2.7 kΩ per channel |
| Operating temperature | -40°C to 85°C |
